Toyota Prius: Settings display

Vehicle settings and displayed content on the screen can be adjusted using the meter control switches in Toyota Prius. These switches provide drivers with the ability to customize various settings related to the multi-information display, allowing for personalization of information shown, display brightness, and other preferences to suit individual driving needs and preferences.

Setting procedure

1. Operate or of the meter control switches and select.
2. Operate or of the meter control switches and select the desired item.

• If the function is turned on and off or the volume, etc. is changed on the setting screen, the setting is changed each time is pressed.
• For functions that allow operation contents, display contents, etc., of function to be selected, the setting screen is displayed by pressing and holding . When the setting screen is displayed, select the setting or desired value (time, etc.) with .

3. After changing the settings, press of the meter control switches.

 (Lane Departure Alert)

Select to set up the following items.

• Lane Departure Alert on/off Select to enable/disable Lane Departure Alert system.
• "Alert Options" Select to set the alert type.
• "Alert Timing" Select to set the alert timing.

 (Blind Spot Monitor) (if equipped)

Select to set up the following items.

• BSM (Blind Spot Monitor) on/off Select to enable/disable the BSM system.
• "Support timing" Select to change the alert timing for an approaching vehicle.
• "Brightness" Select to switch the brightness of the outside rear view mirror indicators.
• "Buzzer alert"

Select to enable/disable the buzzer alert which sounds when BSM system is operated.

 (Pre-Collision System)

Select to set up the following items.

• PCS on/off Select to enable/disable the pre-collision system.
• "Warning timing" Select to change the pre-collision warning timing.

 (Proactive driving assist)

• PDA on/off

Select to enable/disable the PDA system.

• "Sensitivity"

Select to change the alert timing for a detected object.

• SA (Steering Assist)

Select to enable/disable the Steering Assist function.

• DA (Deceleration Assist)

Select to enable/disable the Deceleration Assist function.

• OAA (Obstacle Anticipation Assist)

Select to enable/disable the Obstacle Anticip ation Assist function.

Intuitive parking assist

Select to set up the following items.

• Intuitive parking assist on/off Select to enable/disable the intuitive parking assist.
• "Volume" Select to set the volume of the buzzer which sounds when the RCTA (if equipped), the RCD (if equipped) or intuitive parking assist function is operated.

 (Rear Cross Traffic Alert) (if equipped)

Select to set up the following items.

• RCTA (Rear Cross Traffic Alert) on/off Select to enable/disable the RCTA system.
• "Volume" Select to set the volume of the buzzer which sounds when the RCTA, the RCD (if equipped) and the Intuitive parking assist is operated.

 (Rear Camera Detection) function (if equipped)

Select to enable/disable the Rear Camera Detection function.

 (Parking Support Brake System) (if equipped)

Select to enable/disable the Parking Support Brake function.

 (Safe Exit Assist) (if equipped)

Select to set up the following items.

• Safe Exit Assist on/off Select to enable/disable the Safe Exit Assist system.
• "Sensitivity" Select to change the alert timing for a vehicle or bicycle.
• Mirror indicate on/off Select to enable/disable the outside rear view mirrors display.

 (Road Sign Assist) (if equipped)

Select to set up the following items.

• Road Sign Assist on/off

Select to enable/disable the RSA (Road Sign Assist).

• "Notification Method"

Select to change each notification method used to notify the driver when the system recognizes excess speed and Do Not Enter sign.

• "Notification Level"

Select to change each notification level used to notify the driver when the system recognizes excess speed.

 DRCC

Select to set up the following items.

• "Acceleration Setting"

Select to change the setting for when vehicle accelerates until the set vehicle speed is reached.

• "Guide message"

Select to enable/disable the guide message display

• "Curve Speed Reduction"

Select to change the curve speed reduction function setting.

 Vehicle Settings

• Driver Break Suggestion

Select to enable/disable the drive break suggestion

• LCA (Lane Change Assist) (if equipped)

Select to enable/disable Lane Change Assist system.

• FCTA (Front Cross Traffic Alert) (if equipped)

Select to change the settings for Front Cross Traffic Alert system.

• "TPWS setting" (Tire Pressure Warning Systep>"Tire Set Switching"

  Select to register the tire pressure warning system sensor ID code set.

  • "Tire Rotation"

  Select to register the position of each wheel after performing a tire rotation

  • "Tire Pressure Setting"

  Select to perform the tire inflation pressure setting procedure of the tire pressure warning system.

  • "Pressure unit setting" Select to change the units of measure displayed

  rong>

   (Power Back Door) (if equipped)

  Select to set up the follow

• System settings

Select to enable/disable the power back door system.

• "Opening Adjustment"

Select the open position when power back door is fully open.

• "Volume"

Select to set the volume of the buzzer which sounds when the power back door system operates.

• "Scheduled Maintenance"

Select to reset the scheduled maintenance information (message indicating maintenance is required and distance until the next maintenance) after all maintenance is performed.

• Oil Maintenance Select to reset the Oil maintenance.
• Rear Seat Reminder Select to enable/disable the rear seat reminder function.

 Settings

• "Language" Select to change the language on the multi-information display.
• "Units" Select to change the unit of measure for fuel consumption.
• "Meter Type" Select to enable/disable Hybrid System Indicator.

EV indicator Select to enable/disable the EV indicator.

 (Driving information display settings)

Select to set up the following items.

• "Hybrid System"

Select to enable/disable the ECO Accelerator Guidance

• "Fuel Economy" Select to change the display on Fuel Economy

 (Audio settings)

Select to enable/disable screen.

 (Vehicle information display settings)

• "Display Contents"

Select to display the following items.

"AWD" (AWD models): Select to enable/disable the AWD system display.

• "Drive Info Type"

Select to change the drive information type display between trip and total

• "Drive Info Items"

Select to set the items on the upper and lower side of the drive information screen from three items, average speed, distance and total time.

• Pop-Up Display Select to enable/disable the pop-up displays, which may appear in some situations.
• Default Settings Select to reset the meter display settings.

Tire pressure

• It may take a few minutes to display the tire inflation pressure after the power switch is turned to ON. It may also take a few minutes to display the tire inflation pressure after inflation pressure has been adjusted.
• "---" may be displayed if the tire position information cannot be determined due to unfavorable radio wave conditions.
• Tire inflation pressure changes with temperature. The displayed values may also be different from the values measured using a tire pressure gauge.

Suspension of the settings display

• In the following situations, operation of the settings display will be temporarily suspended.

• When a warning message appears on the multi-information display
• When the vehicle begins to move

• Settings for functions not equipped to the vehicle are not displayed.
• When a function is turned off, the related settings for that function are not selectable.

WARNING

Cautions during setting up the display

As the hybrid system needs to be operating during setting up the display, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This may lead to death or a serious health hazard.

NOTICE

During setting up the display

To prevent 12-volt battery discharge, ensure that the hybrid system is operating while setting up the display features.

Warning message display

Select to display warning messages and measures to be taken if a malfunction is detected

Suggestion function

Displays suggestions to the driver in the following situations.

To select a response to a displayed suggestion, use the meter control switches.

Suggestion to enable the power back door (if equipped)

If the power back door system is disabled (setting  on set to off) and the power back door switch on the instrument panel is operated, a suggestion message will be displayed asking if you wish to enable the power back door system. To enable the power back door system, select "Yes".

After enabling the power back door system, press the power back door switch again to open or close the power back door.

Suggestion to turn off the headlights

If the headlights are left on for a certain amount of time after the power switch has been turned off, a suggestion message will be displayed.

When the headlight switch is in the AUTO position: The message asking if you wish to turn the headlights off is displayed.

To turn the headlights off, select "Yes".

If the driver's door is opened after the power switch is turned off, this suggestion message will not be displayed

Suggestion to close the power windows (Driving at high speeds)

If the vehicle speed exceeds a certain speed with a power window open, a suggestion message will be displayed asking if you wish to close the power windows.

To close all of the power windows, select "Yes".

Customization

The suggestion function can be turned on/off.
