Toyota Prius: Indicators

In the 2024 Toyota Prius, indicators serve to inform drivers about the current operating conditions and statuses of the vehicle's diverse systems. These indicators play a crucial role in keeping drivers informed and aware of the Prius' performance and operational states at all times.

Turn signal indicator

Headlight indicator

Tail light indicator

Headlight high beam indicator

AHB indicator

 Smart key system indicator *1

LTA indicator

LTA indicator

LTA indicator

LDA indicator *2

LDA indicator

LDA indicator

LDA OFF indicator *3, 4

PDA indicator

PDA indicator

Cruise control indicator

Cruise control indicator

Dynamic radar cruise control indicator

 Dynamic radar cruise control indicator

Intuitive parking assist OFF indicator *4, 5

Slip indicator light *6

VSC OFF indicator *4, 6

PCS warning light *4, 6

Driving assist information indicator *4, 6

BSM outside rear view mirror indicators *7 (if equipped)

Brake hold standby indicator *6

Brake hold operated indicator *6

Security indicator *8

"READY" indicator

Low outside temperature indicator *9

 EV indicator

Parking brake indicator

Parking brake indicator

EV drive mode indicator

Eco drive mode indicator

Sport mode indicator

Custom mode indicator

"PASSENGER AIR BAG" indicator lights *8

*1:This light illuminates on the multi-information display with a message.

*2:Except for Puerto Rico

*3:For Puerto Rico

*4:The light comes on when the system is turned off.

*5:Intuitive parking assist OFF indicator turns on when the power switch is turned to ON while the Intuitive parking assist function is on. It will turn off after a few seconds.

*6:These lights turn on when the power switch is turned to ON to indicate that a system check is being performed. They will turn off after the hybrid system is on, or after a few seconds. There may be a malfunction in a system if the lights do not turn on, or turn off. Have the vehicle inspected by your Toyota dealer.

*7:This light illuminates on the outside rear view mirrors.

*8:This light illuminates on the overhead console panel.

*9:When the outside temperature is approximately 37ºF (3ºC) or lower, the indicator will flash for approximately 10 seconds, then stay on.

BSM (Blind Spot Monitor) outside rear view mirror indicators (if equipped)

In order to confirm operation, the BSM outside rear view mirror indicators illuminate in the turning the BSM function/RCTA function on

If the system is functioning correctly, the BSM outside rear view mirror indicators will turn off after a few seconds.

If the BSM outside rear view mirror indicators do not illuminate or do not turn off, there may be a malfunction in the sy this occurs, have the vehicle inspected by your Toyota dealer.
